• Meet the latest IMO regulation and ITU standards, such as IEC 62287-1, ITU-R.M 1371-5.
• Compatible with AIS AtoN, AIS SART, AIS MOB, AIS EPIRB.
• High stability and easy maintenance.
• Built-in isolated DC/DC with wide range input.
• Design for non-Solas vessels with CSTDMA technology.
• Can communicate with other AIS transponders, including shipborne Class A AIS, Class B AIS, AtoN AIS station, AIS base stations.
• CCS type approval.
• RS type approval.

Frequency Range: 156.025~162.025MHz (full channels)

Default Channels: AIS 1, AIS 2

Band Width: 25kHz

Output Power: 2W

Communication Mode: CSTDMA

Sensitivity: Better than -109 dBm

Data Ports: one RS-232, one RS-422

Data Format/Baud Rate: NMEA-0183, 38400bps

Ant Connectors: 50Ω, TNC (GPS Ant), BNC(VHF Ant)

Power Source: 24V DC(12~38V)

Size: 81(H) x 174(W) x 160(D) mm

Weight: 1.4 kg (transponder)

IP Grade: IP22 (Transponder), IP66 (Antenna)
