• Fully complying with the latest international regulation, IMO MSC 74 (69), IMO MSC.302 (87), ITU M.1371-5,IEC 61993-2, IEC 62923-1, IEC 62923-2, etc.
• 7 inch, color LCD, touch screen operation with adjustable brilliance.
• Interface for RADAR, ECDIS, INS, GYRO and external GPS equipment.
• Compatible with AIS AtoN, AIS SART, AIS MOB, AIS EPIRB.
• Built-in isolated DC/DC with wide range input.
• Support all NEMA versions for GNSS/HTG input.
• Port for BAM system connection.
• High stability and easy maintenance.
• CCS type approval.
• DNV type approval.
• RS type approval.
• VR type approval.
• Type approval of Inland AIS by EU.

Frequency: 156.025~162.025MHz
Default Channel: AIS 1, AIS 2
DSC Channel: CH70 (156.525MHz)
TX Power: 12.5W (High)/1W (Low)
I/O Interface: RS422
Power Supply: DC24V（12~38V）
Size: 81(H)x174(W)x257(D)mm(Transponder)  145(H)x264(W)x83(D)mm(MKD)
Weight: 2.3kg(Transponder)  1.25kg(MKD)
IP Grade: IP22(Trsnsponder, MKD), IP66(Antenna)
